Home / Product / Relay for Overvoltage and Undervoltage Protector / Relay for Undervoltage / HJE12A-150A-250VAC Latching RelayProduct Definition: Designed specifically for 250VAC voltage systems, supporting a maximum current load of 150A. It employs advanced magnetic latching technology, maintaining the relay's state after a power outage, ensuring the continuity and reliability of the power system. It is widely used in industrial automation, power control, and energy management.
Core Advantages:
High Load Capacity: Supports a maximum current of 150A, adapting to high-power loads and ensuring stable system operation. Widely used in heavy-duty power equipment.
Magnetic Latching Technology: Utilizes the magnetic latching principle, maintaining the relay's operational state even without power supply, enhancing system stability and safety.
Energy-Saving Design: Low-power operation, reducing energy waste, improving overall system efficiency, and extending equipment lifespan.
High Reliability: High temperature resistance, interference resistance, adaptable to harsh environmental conditions, ensuring long-term stable operation.
Application Scenarios:
Power Protection and Control: Used for protection and fault detection in high-voltage power systems such as distribution networks and substations, ensuring grid safety.
Industrial Automation: Provides precise current control and protection in heavy machinery and production equipment, ensuring normal equipment operation.
Energy Management System: Provides reliable power control solutions for energy management systems such as smart grids and solar power generation.
| Contact Data | |
| Rated load | 150A/48VDC |
| Contact form | 1A&1B |
| Contact material | AgSnO2 |
| Initial contact resistance | 0.6mΩ（0.1A@6vdc) |
| Max. switching current | 150A |
| Max .switching voltage | 48VDC |
| Max.switching power | 7200KW |
| Electrical endurance | ≥6000 ops with resistive load |
| Mechanical endurance | 100000 ops |
| Auxiliary Switch endurance | 100000 ops @ 1A/12VDC |
| CHARACTERISTICS | |
| Insulation resistance | 1000MΩ（at 500VDC) |
| Dielectric strength (Coil to contact) | 4000VAC 1 min |
| Dielectric strength (Across open contact) | 3000VAC 1 min |
| Operate time | Max.30ms |
| Release time | Max.30ms |
| Shock resistance functional | 100m/s2 (10g) |
| Shock resistance destructive | 1000m/s2 (100g) |
| Ambient temperature | -40～85℃ |
| Humidity | 98%RH, +40℃ |
| Vibration resistance | 10-55Hz, 1.5mm(DA) |
| Termination | PCB |
| Unit weight | 50g (Ref.) |
| Construction | Dust protected |
| Coil Power | ||
| Coil type | Pulse Duration | Power Consumption |
| Dual | Min. 50ms | 7.7W |
| COIL DATA | ||||
| Coil Voltage | 6VDC | 9VDC | 12VDC | 24VDC |
| Operating Voltage VDC (min) | 1.8-4.2 | 2.7-6.3 | 3.6-8.4 | 7.2-16.8 |
| Coil Resistance (Ω±10%)@23℃ | 4.7Ω | 10.5Ω | 18.7Ω | 74.8Ω |
